Tungsten carbide wire drawing dies

Ask Lasest Price
Brand Name :	Ri Xin
Model Number :	Various
Certification :	SO9001:2008 ISO14001:2004
Supply Ability :	30 ton per month
Delivery Time :	7-20 days depending on the quantity

Add to Cart

Product Details
Company Profile

Tungsten carbide wire drawing dies

2015 hot sale tungsten carbide wire drawing dies / cemented carbide drawing dies

Description:

We are one of the biggest professional manufactures of Tungsten carbide drawing dies in China. We supply all various types which are suitable for different wires drawing. We have strict quality control and assurance system to guarantee the consistent quality. We only produce the products which you satisfied.

Features: Tungsten carbide is a class of materials widely used in drawing dies because of their superior strength, toughness and wear resistance. All major wire producers can use drawing dies, which include wire drawing dies, tube drawing dies, bar drawing dies.

Recommended grade: As below
We can make suggestions of suitable grades for customers' usage.
Type: S11, S12, S13, LV, LE, W, S22, S23, S30, S40, S41, S42, S60 and various
The sizes are as per China new technical standard.

Grade:

			Properties & Applications	Grades
Density	T.R.S	Hardness
g/cm³	MPα	HRA
14.95	91.5	1800.0	It is suitable for drawing steel and nonferrous metal wires or bars whose diameter are less than Φ6.00mm under low stress.	YG6X
14.95	90.5	1900.0	It is suitable for drawing steel wire and nonferrous metal and alloy bars whose diameter are less than Φ20.00mm under high stress and also for drawing tubes less than Φ10.00mm.	YG6
14.8	89.5	2200.0	It is suitable for drawing steel and nonferrous metal and alloy bars and tubes, also for manufacturing mechanical parts, tools and wear parts.	YG8
14.5	88.5	2400.0		YG10
14	87	2800.0	It is suitable for drawing steel bars and tubes with high compression rate and for manufacturing anvils, drilling and punching tools under great stress.	YG15

Package
